80x80x25 24v 48v DC Laptop cpu Cooling Fan

AD80-25T

80x80x25 24v 48v DC Laptop cpu Cooling Fan

A Leader in Innovation

Each year, Shyuan Ya raises the bar further by incorporating the cutting edge designs and the high quality materials into 80x80x25 24v 48v DC Laptop cpu Cooling Fan. High precision bearings, which are long life and maintenance free, are all standard. Additionally, each 80x80x25 24v 48v DC Laptop cpu Cooling Fan carries Shyuan Ya's patented silicon lamination designs which have higher metal induction and lower magnetic loss than any other manufacturer. Most importantly, 100% products inspection is conducted in the end of production line in order to provide high standard and reliable products toward customers.




 Quick Detail 1

80x80x25mm12v brushless table dc motor laptop cooling fan

Air Flow : 30 ~ 37 CFM

Housing : Thermoplastic PBT, UL94V-0

Impeller : Thermoplastic PBT, UL94V-0

Bearing : Ball or Sleeve

Termination : Lead Wire UL 1007 AWG#24

                        Red Wire: Positive Voltage (V+)

                        Black Wire: Negative Voltage (V-)

                        Yellow Wire: Function

Operating Temperature : -10°C to +70°C for Sleeve Type

                                               -20°C to +80°C for Ball Type

Weight : 100g

Function : Function type is optional

                  P: Lock Protection

                  A: Rotation Detector

                   I: Frequency Generator



80x80x25mm12v brushless table dc motor laptop cooling fan

SHYUAN YA



Professional & Customized Service



SHYUAN YA Group was founded in 1982 with more than 30 years experience in fan industry. Our professional teams in molding and R&D departments can provide technical suggestions and customized services to our customers.

Besides,up to 85% of fan components including fan motors are made in our factories which located in Taiwan.








Short Production Time & Prompt Delivery



SHYUAN YA Group has invested over two million US dollars on upgrading production facilities & inspection equipment.Our production lines include plastic injection, motor winding, and die casting processing lines.

Most importantly, maximum 16 Assembling lines can shorten production time which normally takes about 4~6 weeks.







Quality Stability & Reliability



To ensure that high standard and reliable products are delivered to our customers,100% products inspections are conducted at the end of production line. Our main inspection equipment includes Semi-Anechoic Room which is one of the biggest sizes in the fan industry and background noise down to 10.0 dBA

The air flow chamber that can be used for measuring air flow for any kind of fan.

and measurement range up to 1,300 CFM.



80x80x25mm12v brushless table dc motor laptop cooling fan


Packing and Delivery.jpg

Customer Services:

1. Warranty: 1 year warranty for all products.

2. Private Labelling: All of axial fans are able to be Private labeled.

3. Products Quality: 100% products inspection before delivery.

4. Just in time delivery: Normally, Lead time is 30 days.

5. Customized Service: As we have our own molding department,

    customized service can be provided.

6. Prompt customers Services: E-mail will be replied in 24 hours.




Questions & Answers:

Q: What information do you need to provide in order to get a quotation?

A: Generally, information about Size、Air Flow、Voltage of required fans

is needed in order to select a right fan for you and provide you a quotation.

Q: Can I have samples for testing before ordering products?

A: Yes, we sincerely suggest that customers should have some samples

of required fans for testing because the truly performance of fans can be

fully demonstrated after testing is conducted.

Q: Can I have a discount for the quoted price?

A: The quoted price is based on annual usage quantity. If annual usage

quantities increase, please provide the information to our sales.

We will provide you a further discount.

Q: What is the warranty of products?

A: All of our products have 1 year warranty. Every product has its own

production code. This code is able to track the production time.

Q: Could you print our company LOGO on the nameplate and package?

A: Yes, we accept OEM orders.



80x80x25mm12v brushless table dc motor laptop cooling fan
