40mm 4cm 5vdc 12v 2-pin computer cpu micro fan axial

Model No.
Made in
Request for Quotation

    Innovator in Air Movement Solutions


    • Type:High Pressure

    Key Features

    40mm 4cm 5vdc 12v 2-pin computer cpu micro fan axial


    Quick Detail 1

    40mm 4cm 5vdc 12v 2-pin computer cpu micro fan axial

    Air Flow  : 5.8 ~ 8.1 CFM

    Housing  : Thermoplastic PBT, UL94V-0

    Impeller  : Thermoplastic PBT, UL94V-0

    Bearing  : Ball or Sleeve

    Termination  : Lead Wire UL 2468 AWG#26

                            Red Wire: Positive Voltage (V+)

                            Black Wire: Negative Voltage (V-)

                            Yellow Wire: Function

    Operating Temperature  : -10°C to +70°C for Sleeve Type

                                                    -20°C to +80°C for Ball Type

    Weight  : 24.3g

    Function  : Function type is optional

                      P: Lock Protection

                      A: Rotation Detector

                       I: Frequency Generator




    40mm 4cm 5vdc 12v 2-pin computer cpu micro fan axial  Fan


    Company Overview 1.jpg


    Professional & Customized Service


    SHYUAN YA Group was founded in 1982 with more than 30 years experience in fan industry. Our professional teams in molding and R&D departments can provide technical suggestions and customized services to our customers.

    Besides,up to 85% of fan components including fan motors are made in our factories which located in Taiwan.


    198230 years experienceUp to 85%
    Set upManufacturing experienceSelf-Manufacturing


    Production Equipment 1


    Short Production Time & Prompt Delivery


    SHYUAN YA Group has invested over two million US dollars on upgrading production facilities & inspection equipment.Our production lines include plastic injection, motor winding, and die casting processing lines.

    Most importantly, maximum 16 Assembling lines can shorten production time which normally takes about 4~6 weeks.


    Over two million US dollars16 lines4~6 weeks
    Investment fundsAssembling linesMass Production


    Inspection Equipment 1.jpg


    Quality Stability & Reliability


    To ensure that high standard and reliable products are delivered to our customers,100% products inspections are conducted at the end of production line. Our main inspection equipment includes Semi-Anechoic Room which is one of the biggest sizes in the fan industry and background noise down to 10.0 dBA

    The air flow chamber that can be used for measuring air flow for any kind of fan.

    and measurement range up to 1,300 CFM.


    100% products inspectionsDown to 10.0 dBAUp to 1,300 CFM
    High standardBackground noiseMeasurement range

    40mm 4cm 5vdc 12v 2-pin computer cpu micro fan axial

    Packing and Delivery.jpg

    Customer Services:

    1. Warranty: 1 year warranty for all products.

    2. Private Labelling: All of axial fans are able to be Private labeled.

    3. Products Quality: 100% products inspection before delivery.

    4. Just in time delivery: Normally, Lead time is 30 days.

    5. Customized Service: As we have our own molding department,

        customized service can be provided.

    6. Prompt customers Services: E-mail will be replied in 24 hours.


    Questions & Answers:

    Q: What information do you need to provide in order to get a quotation?

    A: Generally, information about Size、Air Flow、Voltage of required fans

    is needed in order to select a right fan for you and provide you a quotation.

    Q: Can I have samples for testing before ordering products?

    A: Yes, we sincerely suggest that customers should have some samples

    of required fans for testing because the truly performance of fans can be

    fully demonstrated after testing is conducted.

    Q: Can I have a discount for the quoted price?

    A: The quoted price is based on annual usage quantity. If annual usage

    quantities increase, please provide the information to our sales.

    We will provide you a further discount.

    Q: What is the warranty of products?

    A: All of our products have 1 year warranty. Every product has its own

    production code. This code is able to track the production time.

    Q: Could you print our company LOGO on the nameplate and package?

    A: Yes, we accept OEM orders.

    40mm 4cm 5vdc 12v 2-pin computer cpu micro fan axial

    Payment Details

    • Payment Terms:TT ,PayPal
